ShowLift
The ShowLift is a variable height staging platform or riser. It can be used in a variety of applications
where surface levels need to be adjusted to serve different types of events.
The ShowLift is a fully customized product and can therefore be fabricated to meet different travel
distances, sizes, shapes and finishes.
The movement of the ShowLift can be via a simple ½” drill adaptor, a fixed speed motor with limit
switches or a motion-controlled system with preset positions.
The ShowLift can support a maximum static live load on the deck of 5KN/m2 (104.43 psf) and a maximum
concentrated load on the decks of 3kn over a surface of 300mm2 (675 lbs psf).
Engineered and manufactured in Canada.
